720W N-Type Bifacial Solar Panel 132 Cells

Model Series: PLM-720DH2N-132
Maximum Power (Pmax): 700W - 720W
Module Efficiency (η): 22.53% – 23.17%
Open Circuit Voltage (Voc): 48.80 – 49.28V
Short Circuit Current (Isc): 18.35 – 18.55A
Voltage at Max Power (Vmp): 40.35 – 41.03V
Current at Max Power (Imp): 17.35 – 17.55A
Cell Orientation: 132 half-cells (6×22)
Dimensions: 2384 × 1303 × 33mm
Weight: 37.9kg
Front Glass: 2.0mm high transmittance, HR coated tempered glass
Rear Glass: 2.0mm semi-tempered glass
Frame: Anodized aluminum alloy frame
Junction Box: IP68, 3 diodes
Output Cable: 4.0mm², +400mm / -200mm
Maximum System Voltage: 1500V DC
Maximum Series Fuse Rating: 35A
Operational Temperature: -40°C to +85°C
Temperature Coefficient (Pmax): -0.30%/°C
Temperature Coefficient (Voc): -0.25%/°C
Temperature Coefficient (Isc): +0.046%/°C
NMOT: 45±2°C
Wind Load: 2400Pa
Snow Load: 5400Pa
Maximum Bifaciality: 80±5%
Power Output Tolerance: ±3%
Application: Commercial, utility-scale, rooftop, PV plants

Send Inquiry

Products Description

The 720W N-Type Bifacial Solar Panel 132 Cells is a next-generation high-efficiency photovoltaic module designed for commercial, utility-scale, rooftop, and PV plant applications. Featuring advanced N-type half-cell technology with 132 cells arranged in a 6×22 configuration, the 720W N-Type Bifacial Solar Panel 132 Cells captures sunlight from both front and rear sides, delivering up to 794.8Wp under bifacial enhancement conditions. With a maximum rated power of 720W and module efficiency reaching 23.17%, the 720W N-Type Bifacial Solar Panel 132 Cells achieves industry-leading performance.

Products Feature

Higher Power Output with 132 Half-Cells – The 720W N-Type Bifacial Solar Panel 132 Cells uses a 132-cell (6×22) layout to achieve 720W rated power and 23.17% module efficiency, delivering superior energy yield.

Superior Bifacial Energy Gain – The 720W N-Type Bifacial Solar Panel 132 Cells generates extra energy from the backside depending on ground albedo, with maximum bifaciality of 80±5%, reaching 794.8Wp under optimal rear-side reflection.

Excellent Temperature Coefficients – With a Pmax temperature coefficient of only -0.30%/°C and NMOT of 45±2°C, the 720W N-Type Bifacial Solar Panel 132 Cells maintains high performance even in elevated operating temperatures.

Dual-Glass Durability – Featuring 2.0mm high-transmittance HR coated tempered front glass and 2.0mm semi-tempered rear glass, the 720W N-Type Bifacial Solar Panel 132 Cells provides superior protection against micro-cracks, PID, and environmental stress.

High System Voltage & Load Capacity – Rated for 1500V DC maximum system voltage with 35A maximum series fuse rating, the 720W N-Type Bifacial Solar Panel 132 Cells withstands wind loads of 2400Pa and snow loads of 5400Pa for diverse climate conditions.

IP68 Junction Box with 3 Diodes – Built for reliability, the 720W N-Type Bifacial Solar Panel 132 Cells is equipped with an IP68-rated junction box that provides excellent protection against moisture and dust ingress.

Sustainable Manufacturing – Constructed with a high percentage of recyclable materials, the 720W N-Type Bifacial Solar Panel 132 Cells represents an environmentally responsible choice.

Comprehensive Certifications – Manufactured under ISO 9001:2015 quality management system, the 720W N-Type Bifacial Solar Panel 132 Cells complies with IEC 61215 and IEC 61730 standards.
